General specifications


Switching functionNormally open (NO)


Output typeTwo-wire


Rated operating distance15 mm


Installationflush


Output polarityAC/DC


Reduction factor r_Al0.5


Reduction factor r_Cu0.45


Reduction factor r₃₀₄0.75


Output type3-wire


Nominal ratings


Switching frequency30 Hz


Hysteresis3 ... 15 % typ. 5 %


Reverse polarity protectionreverse polarity tolerant


Short-circuit protectionyes


Voltage drop≤ 8 V


Rated operating current4 ... 500 mA AC/DC


Off-state current≤ 0.8 mA


Operating voltage indicatorLED, green


Switching state indicatorLED, yellow


Functional safety related parameters


MTTF_d1036 a


Mission Time (T_M)20 a


Diagnostic Coverage (DC)0 %


Electrical specifications


Rated operating voltage20 ... 250 V AC/DC


Compliance with standards and directives


Standard conformity


StandardsEN IEC 60947-5-2


Approvals and certificates


UL approvalcULus Listed, General Purpose


CSA approvalcCSAus Listed, General Purpose


CCC approvalCertified by China Compulsory Certification (CCC)


Ambient conditions


Ambient temperature-25 ... 70 °C (-13 ... 158 °F)


Storage temperature-40 ... 85 °C (-40 ... 185 °F)


Mechanical specifications


Connection typeConnector plug


Housing materialbrass, nickel-plated


Sensing facePBT


Degree of protectionIP67


Connector


Threading1/2"-20 UN


Number of pins3


Dimensions


Length60 mm


Diameter30 mm

">
